Gidrobeton SRG-F1 — fibre-reinforced shrinkage-compensated repair mortar
Kalmatron

Gidrobeton SRG-F1 — fibre-reinforced shrinkage-compensated repair mortar

Thixotropic repair mortars

Polypropylene fibre and compensated shrinkage are the main features of Gidrobeton SRG-F1, made with Portland cement and aggregate up to 5 mm. It is used to repair defects in concrete and reinforced concrete structures in interior and exterior work, including in tanks and treatment plants. At 28 days the compressive strength is at least 50 MPa, flexural 4.5 MPa, bond to concrete 2.0 MPa, frost resistance at least 300 cycles.

Specifications

ManufacturerKalmatron — OOO “Kalmatron-SPb”, Saint Petersburg
Typethixotropic repair mortars
Usetanks and treatment plants, floors
Baseshrinkage-compensated dry mix: Portland cement, mineral aggregate up to 5 mm (granite screenings, quartz sand), a complex of patented chemically active reagents, polypropylene fibre
Colourgrey (free-flowing grey powder)
Packagingbags of (25±0.25) kg
Application methodthe substrate must be clean and sound: remove plaster, paint, whitewash, loose and delaminated concrete down to “sound” concrete (with a rotary hammer), dust, dirt and oils; clean exposed rebar of concrete around its full circumference for 20 mm and of rust; saturate the surface with water, remove the excess with a rag; water 160–170 ml per 1 kg (4 l per 25 kg), mixing for 3–5 min, 5 min pause, remixing; adding water is prohibited; applied with a trowel, spatula or mason’s trowel to a moistened surface; repair of defects in interior and exterior work
Application temperaturesurface not below +5 °C; mortar not below +5 °C (in cold weather — warm water not above +35 °C)
Curingmoist curing for 3 days: wet with water every 3–4 h starting immediately after setting; protect from direct sun, rapid drying, draughts, temperature fluctuations and rain; the screed can be walked on after 12–24 h
Key propertieswatertightness at least 12 atmospheres; frost resistance at least 300 cycles; compressive strength at 28 days at least 50 MPa; flexural strength at 28 days at least 4.5 MPa; adhesion to concrete at 28 days at least 2.0 MPa; shrinkage compensated (GOST 24544-81); maximum aggregate size 5 mm; working time 30–40 min; service temperature -60…+130 °C
Shelf life6 months in undamaged original packaging; covered dry room, air humidity no more than 70 %, not below +5 °C
StandardsTU 5745-009-54282519-2008 “Cement-based waterproofing repair compounds” (amendment No. 1); GOST R 56378-2015; declaration ROSS RU D-RU.PA01.V.19883/19 of 06.02.2019 valid until 05.02.2029; expert opinion No. 04E.0312.251 of 13.03.2012

Data from the manufacturer’s technical data sheet. The coating system, number of coats and quantity are selected for your project on request.
