LEVL (INGRI)
LEVL Coat 310 — epoxy self-levelling floor, class KM1
Self-levelling epoxy coating with a certified fire hazard class KM1 for warehouses, car parks, schools and healthcare facilities.
Price on request
LEVL (INGRI)
LEVL Coat 151 — polyurethane primer under polyurethane floors
Under LEVL polyurethane floors, including LEVL Coat 251 and 351, the substrate is prepared with LEVL Coat 151 primer. The one-component urethane-containing prepolymer cures with air moisture, penetrates the substrate well and seals it, at the same time increasing the strength of the mineral surface. Work is possible at air temperatures from −10 to +30 °C; two coats are applied on absorbent surfaces, one on non-absorbent ones. The primer is also suitable for metal; adhesion to concrete in a system with LEVL Coat 351 is at least 2.5 MPa.
Specifications
| Manufacturer | LEVL (INGRI) — OOO “Ingri”, Saint Petersburg |
|---|---|
| Type | floor primers |
| Base | solution of a urethane-containing prepolymer in an organic solvent; one-component, cures with air moisture |
| Colour | clear brownish liquid; on concrete gives a “wet” concrete look, on metal a gloss coating |
| Packaging | 19 kg pail, 220 kg drum (ready to use) |
| Application method | priming and impregnation of substrates before polyurethane coatings; strengthening of mineral substrates; velour roller, brush or by machine; 2 coats on absorbent substrates, 1 coat on non-absorbent ones; next coat after curing, no later than 24 h |
| Application temperature | air and substrate from −10 to +30 °C (recommended +10…+25 °C); material +5…+30 °C; air humidity 40–80 %; substrate moisture no more than 4 % by weight; 3 °C above the dew point |
| Curing | at 75–80 % humidity: light loads +10 °C 24 h, +20 °C 12 h, +30 °C 8 h; foot traffic 5 / 3 / 2 days; full strength gain 8 / 6 / 4 days; drying to degree 3 no more than 8 h |
| Key properties | Adhesion to concrete (together with LEVL Coat 351 coating) at least 2.5 MPa; density 0.98 ± 0.05 g/cm³; non-volatile content 45 ± 1 %; high penetrating and sealing ability; service temperature from −20 to +60 °C |
| Consumption | on absorbent mineral substrates ~400 g/m² (in 2 coats); on non-absorbent substrates 100–150 g/m² (in 1 coat) |
| Shelf life | 18 months from the date of manufacture; storage at +5…+25 °C |
| Standards | TU 2312-002-94613022-06 with Amendment No. 1; works per SP 29.13330.2011 and SP 71.13330.2017; test methods GOST 31992.1, GOST R 31939, GOST 19007, GOST 28574 |
Data from the manufacturer’s technical data sheet. The coating system, number of coats and quantity are selected for your project on request.
Other materials by LEVL (INGRI)
LEVL (INGRI)
LEVL Coat 161 — polyurethane hardening impregnation for concrete
One-component impregnation for weak porous mineral substrates; applied at air temperatures down to −10 °C, service from −60 °C.
Price on request
LEVL (INGRI)
LEVL Concrete Strong 24 — lithium impregnation concentrate for concrete
Lithium silicate concentrate diluted with water 1:1 and used for hardening and dustproofing concrete and polished floors.
Price on request
LEVL (INGRI)
LEVL CemPol 50 “terrazzo” — cement mix for polished terrazzo floors
Base for a decorative ground terrazzo floor in retail and public buildings; the colour is set by the aggregate, strength 45 MPa at 28 days.
Price on request
LEVL (INGRI)
LEVL Coat 111 — epoxy impregnation for hardening concrete
Two-component epoxy impregnation for dustproofing and hardening porous mineral substrates; adhesion to concrete over 4.0 MPa.
Price on request
LEVL (INGRI)
LEVL Coat 251 — matt polyurethane enamel for floors and walls
One-component RAL paint coating for workshops, warehouses, car parks and public buildings; applied at temperatures from −10 °C.
Price on request
