IZOLEP-oil 350 AS — antistatic epoxy coating for light petroleum products
VMP

IZOLEP-oil 350 AS — antistatic epoxy coating for light petroleum products

Tank coatings

An antistatic epoxy coating for the internal surface of storage tanks, containers, tank cars and process pipelines where light petroleum products and aviation fuel are stored and pumped. An additive that increases electrical conductivity provides a volume resistivity of no more than 10⁹ Ω·m, so the coating does not accumulate static charge. It is resistant to petrol, aviation and diesel fuel, gas oils, white spirit, liquefied natural gas and sea water; it is approved by FSUE GosNIIGA, and the predicted service life is 20 years.

Specifications

ManufacturerVMP — AO “NPKh VMP”, Yekaterinburg
Typetank coatings
Baseepoxy, two-pack, amine hardener; antistatic (additive to increase electrical conductivity); abrasion-resistant
Colourblack, grey
Packagingkit: base in metal pails, hardener in metal cans
Application methodairless spray (nozzle 0.015–0.021″, 15–25 MPa), air spray, brush, roller; thinner SOLV-EP max. 5 % by weight (recommended at +30…+40 °C); base : hardener 6.5:1 by weight, 5:1 by volume
Application temperatureapplication and curing at air temperatures from +5 to +40 °C, relative humidity max. 80 %; surface at least 3 °C above the dew point but not above +40 °C; material not below +15 °C
Dryingat 23 °C, max.: to degree 1 — 5 h, to degree 3 — 8 h; pot life 2 h at +20 °C (3.5 h at +15 °C, 1 h at +30 °C)
Key propertiesaverage volume solids — 57 %, non-volatile matter by weight — 65–70 %, density — 1.15–1.25 g/cm³, volume resistivity — max. 10⁹ Ω·m (the coating does not accumulate static charge), reinforced-type coating with a predicted service life of 20 years (NII Transneft), service temperature in liquid media — up to +60 °C (short-term up to +75 °C), withstands steaming, resistance to light petroleum products (petrol, aviation and diesel fuel, gas oils, gas condensate distillate, white spirit, solvent, nefras), liquefied natural gas, sea water, metalworking fluids and cleaning liquids
Compatible materialsstand-alone coating; at PJSC Transneft facilities the first coat is grey, the second black; compatible with IZOLEP-oil 250
Shelf life24 months from the date of manufacture
StandardsTU 20.30.12-081-12288779-2017; complies with the normative documents (ND) of Gazprom, Transneft, Rosneft, Lukoil, Irkutsk Oil Company, Surgutneftegas, Gazprom Neft; approved by NII Transneft, FSUE GosNIIGA; state registration certificate No. RU.66.01.40.015.E.000110.08.17 of 24.08.2017

Data from the manufacturer’s technical data sheet. The coating system, number of coats and quantity are selected for your project on request.
