MGTN, or TECHNONICOL mastic No. 24, is a homogeneous cold mass of petroleum bitumen with fillers, process additives and solvent. Its purpose is coating waterproofing of concrete, reinforced concrete, timber and other structures that are buried in the ground and in contact with a damp environment; the mastic is not used for roof coverings. The non-volatile content is at least 65%, heat resistance is not lower than +80 °C, and flexibility on a bar is retained down to −5 °C. It can be applied from −20 to +40 °C by brush or by pouring; packaging — 10 kg euro pail.
| Manufacturer | TECHNONICOL — OOO “Zavod Technoflex”, Uchaly, Voskresensk |
|---|---|
| Type | mastics and liquid membranes |
| Use | foundations and basements |
| Base | ready-to-use homogeneous mass of petroleum bitumen with process additives, mineral fillers and solvent (cold-applied) |
| Packaging | 10 kg metal pails |
| Application method | for concrete, reinforced concrete, timber and other structures buried in the ground and in contact with a damp environment; stir before use; substrate dry and clean; priming with TECHNONICOL primers No. 01 and No. 08; apply coat by coat by brush or by pouring and spreading with squeegees, wet coat not more than 2 mm, the next coat after the previous one has dried and across it; do not use for roof coverings; do not thin with solvents at low temperatures, do not mix with diesel fuel |
| Application temperature | from −20 to +40 °C; below +5 °C keep the mastic at room temperature for at least a day; below +15 °C the viscosity and drying time increase |
| Curing | drying of one coat 12–24 h; final development of properties — 7 days |
| Key properties | bond strength to concrete at least 0.1 MPa, to metal at least 0.1 MPa (GOST 26589-94); non-volatile content by mass at least 65% (GOST 31939-2022); heat resistance not lower than +80 °C; flexibility temperature on a bar R = 5 mm not higher than −5 °C; watertightness at a pressure of 0.03 MPa for 10 min — passes (GOST 26589-94); combustibility group G4 (GOST 30244-94), ignitability V3 (GOST 30402-96), flame spread RP4 (GOST R 51032-97) |
| Layer thickness | wet coat not more than 2 mm |
| Consumption | per coat approx. 1 kg/m² (horizontal) and approx. 0.7 kg/m² (vertical); anti-capillary barrier and protection of concrete against corrosion 1.0 kg/m²; waterproofing of structures 2.5–3.5 kg/m² |
| Shelf life | 18 months from the date of manufacture; in a dry, ventilated room protected from the sun, with supply and exhaust ventilation, at −20…+30 °C, pallets in a single tier, following the rules for highly flammable materials |
| Standards | TU 5775-034-17925162-2005; GOST 30693-2000 |
Data from the manufacturer’s technical data sheet. The coating system, number of coats and quantity are selected for your project on request.
