AkvaVIS S404 — polyurethane resin for consolidating soils and rocks

Other concrete repair materials

AkvaVIS S404 is a two-component polyurethane resin used to consolidate soils and rocks, seal off groundwater, strengthen foundations and carry out work using the “wall in soil” (diaphragm wall) technique. The material is produced in versions B, S and M with different reaction times: without water the reaction starts after 15 s, 90–150 s and 40 min respectively. The resin is injected with a pump through metal packers with mixing in a static mixer; it does not shrink, foams up to 1:10 and is suitable for cracks with an opening of more than 0.25 mm.

Specifications

ManufacturerAkvaVIS — OOO “GELIOS”
Typeother concrete repair materials
Usetunnels and metro, hydraulic structures and dams
Basetwo-component polyurethane resin for consolidating soils and rocks; versions B, S, M (different reaction times)
Application methodsoil analysis before the work; one-component piston pump with a 1 : 1 ratio, mixing in a static mixer gun; metal packers; keep at +17…+22 °C for 24 hours beforehand; A : B ratio 1 : 1.2 by weight (1 : 1 by volume)
Curingstart of reaction without water: B — 15 s, S — 90–150 s, M — 40 min; gelation (20 °C): 40 s / 0.5–1 min / 40–120 min; curing: 3 / 5 / 240 min
Key propertiesviscosity (25 °C): component A 500, B 200 mPa·s; density A 1.04±0.03, B 1.23±0.03 g/cm3; foaming ratio up to 1 : 10 (4–10 times in free space), without water — 2 times; no shrinkage; for cracks with an opening of more than 0.25 mm
StandardsSTO 69626291-001-2012

Data from the manufacturer’s technical data sheet. The coating system, number of coats and quantity are selected for your project on request.
