CarbonWrap® Resin 300+ two-component epoxy saturating resin — for tapes and fabrics

Composite strengthening

CarbonWrap Resin 300+ is a solvent-free two-component epoxy saturating resin used to impregnate carbon, aramid, basalt and glass fabrics and tapes of the CarbonWrap external reinforcement system. In the “wet” method it also serves as the primer resin, so no separate primer is needed; the components are mixed at a ratio of 100:30 by weight, and the pot life at 20 °C is at least 60 min. The bond to concrete exceeds 2.5 MPa with failure in the concrete, the shear strength is at least 12 MPa, and the kit weighs 19.5 kg.

Specifications

ManufacturerCarbonWrap — OOO “Nanotekhnologicheskiy tsentr kompozitov”, Moscow
Typecomposite strengthening
Basetwo-component epoxy saturating resin: component A — thixotropic blend of epoxy resins, reactive diluents, fillers, pigments and functional additives; component B — polyamine hardener with filler and special additives; solvent-free
Colourcomponent A — ivory; component B — colourless; mix — light grey
Packagingkit of 19.5 kg: component A — 15 kg metal pails, component B — 4.5 kg metal pails
Application methodprimer resin for a system laid by the “wet” method; no separate primer required; A:B = 100:30 by weight; mixing with a low-speed mixer at 300–400 rpm with a paddle for 5 min, especially at the bottom and walls, until uniformly light grey, then 1 min at low speed to reduce air entrainment
Application temperatureair +10…+35 °C; relative humidity no more than 80 %
Curingfull cure 7 days at 20 °C; at temperatures below 20 °C the pot life increases
Key propertiesdynamic viscosity, Brookfield RVT at 25 °C, 20 rpm: A (N=4) 2000–8000, B (N=2) 12–40 Pa·s; mix density at 20 °C no more than 1.2 g/cm3; pot life at 20 °C at least 60 min; bond strength (adhesion) > 2.5 MPa (failure in the concrete); shear strength (7 days at 23 °C) at least 12 MPa
Shelf life36 months from the date of manufacture; in intact factory packaging in warehouses at +5…+30 °C; do not stack pallets with components on top of each other
StandardsTU 20.16.40-105-38276489-2023; STO No. 38276489.001-2017, STO No. 38276489.002-2017, STO No. 38276489.003-2017; TTK NTsK.4399.00001; certificate of conformity to the TU, certificate of conformity to the technical regulation on fire safety requirements, sanitary and epidemiological conclusion, SGR

Data from the manufacturer’s technical data sheet. The coating system, number of coats and quantity are selected for your project on request.
